A single button does it all.
Push and hold the one and only button to turn on the device, tap it to
switch between polarized and non-polarized modes, push & hold it to turn
off your DL3.
Better contrast, better image.
Each DL3 comes with a fully enclosed, all-aluminum spacer, and an aluminum
& rubber eyepiece for optimum image contrast and reduced internal
reflections.
The complete set DL3 includes a charging base,
eyepiece, leather belt case, spacer, and lanyard.
|
DermLite 3
Optical Excellence, Functional Beauty
The DL3 has been developed to be the tool of choice for
the world's leading dermatologists. Precision-engineered and crafted from solid
aluminum, it is the first handheld DermLite to integrate a 25mm four-element
lens, which offers greatly reduced optical distortion and a sharper image
across the field of view, cross-polarized & non-polarized lighting,
low-battery indicator, charging base, and a fully enclosed, removable aluminum
faceplate spacer.
HIGH-POWERED DIODES FOR A BRIGHTER VIEW IN BOTH POLARIZATION MODES In
each DL3, twenty-one high-powered LEDs produce approximately 30% more
illumination in cross-polarized mode than in a DermLite II HR, and seven
non-polarized LEDs for immersion fluid dermoscopy create a brighter image than
the equivalent mode in a DermLite II hybrid. For optimum ease of use, one
button does it all: A quick tap instantly toggles between polarization modes,
and a longer push turns the unit on or off.
UNSURPASSED FOCAL RANGE, FULLY ENCLOSED SPACER
A major step forward is the DL3's fully retractable faceplate spacer design and
focusing mechanism. By twisting a large precision dial that is as easy to turn
when mounted on a camera as it is during regular use, you extend its faceplate
spacer and focus your image with an available focal range in excess of ±4mm or
-5.5 to +7.6 diopters (DermLite II: ±1mm). The innovative spacer comes with a
glass faceplate with 10mm scale, and due to its fully enclosed design, it is
easy to clean and keeps the critical optical components completely sealed. Now,
contaminants as well as undesirable ambient lighting no longer affect your
image.
CAMERA COMPATIBLE
Of course, the DL3 is camera compatible. Attach your digital camera* via the
product's built-in threaded 28mm connection, extend the spacer, and start
taking sharp, glare-free images quickly and easily. The same 28mm connection
may be used to mount the included eyepiece, which may greatly improve the
contrast of the image and helps reduce internal reflections caused by ambient
lighting
CHARGING BASE & LOW-BATTERY INDICATOR
DL3 is powered by the same integrated, rechargeable lithium-ion battery used in
the DermLite II series, which can be recharged via the included charging base.
A DermLite DL3 will let you know when it's time for a recharge: While using a
fully charged DL3, the "3" on the top of the unit lights up green; once the
charge level drops below 25%, the "3" will glow orange.
DermLite DL3 combines the unique advantages of polarized and immersion fluid
dermoscopy in one truly refined device that offers superior illumination and
optics, solid durability, and, with its ergonomic handle design and single
button operation, a degree of convenience that is unsurpassed in a DermLite.
Each unit comes with 3Gen's 5-year warranty, includes a leather belt case,
lithium battery and charging base, eyepiece, and lanyard.
-
up to 2500 footcandles of light (at faceplate)
-
polarized or non-polarized
-
retractable, fully removable faceplate with 10mm scale
-
four-element 25mm 10x lens
-
28 high-powered light-emitting diodes (LED)
-
rechargeable lithium-ion battery & charging base
-
compact all-aluminum design
-
includes leather belt case
Warranty: 5 years
|
